| Press system |
Hydraulic |
NC control |
NISSHINBO PAL-510T |
| Pressing capacity |
30 ton |
Control axis |
Simultaneous 4=X,Y,T,C |
| One sheet size |
1250*2500 mm |
Table feeding speed |
X=60m/min |
| Max. thickness |
6.35mm |
|
Y=60m/min |
| Max. diameter |
Φ100mm |
Turret rotation |
30rpm |
| Max. work loading weight |
180kg |
Punching frequency |
220hit/min |
| Max. weight on the Max. speed |
100kg |
Nibbling Frequency |
X450spm, Y420spm |
| Power consumption |
37KVA |
Punching accuracy |
±0.1mm/1000mmL |
| Machine weight |
17 ton |
|
|
|
>
